HARDWARE

POS

  • HOME
  • >
  • HARDWARE
  • >
  • POS
pos_01 pos_02 pos_03 pos_04 pos_05
pos
구분 항목 사양
기본사양 CPU & Chipset

Intel®Celeron® J1800 Dual Core(2.58 GHz 1M Cache)

Intel®Celeron® J1900 Quad Core (2.0GHz, 2M Cache)

System on chip (SoC)

Memory GB DDR3 1333MHz, SoDIMM (Up to 8GB)
Storage

2.5", SATA-III SSD 64GB↑

Support IDE/ACHI mode

Display 15", 1024 X 768, 24Bit, Luminance : 300 cd/㎡, Backlight : LED
Dual Display port 1EA HDMI, Intel® HD Graphics
LAN 1EA (Realtek RTL8111F PCIe GbE Controller)
Serial

5EA (DSUB-9p x 2EA / RJ-45 x 3EA)

Support Powered COM1,2 (select by BIOS)

Parallel(LPT) -
PS/2 -
USB 4EA(I/O)(USB3.0&2.0), 2EA (Rear) (USB 2.0)
Audio Line-Out
Speaker 1 EA (1W) (Internal Speaker)
Cooler & FAN Fanless
Power Adaptor 60[W] Adaptor, Input AC 100~240V/50~60HZ, DC 12V/5A
Dimension(mm) 384(W) x 347(H) x 225(D) (Normal Angle, With Stand)
Weight 4.8kg
OS supported POSReady7 / Windows 10 IoT / Linux / Android
옵션사양 OS POSReady7 / Windows 10 IoT
Storage 2.5", SATA-III HDD 500
Touch Panel

15"Bezel type, 5-Wire Resistive

15”Bezelless type, Projective Capacitive Touch

Dual Display 9.7", TFT-LCD, 1024x768, LED panel (Touch)
Customer Display VFD type, 20 Characters X 2 Lines, Serial(RS-232C)
Secure Card Reader EMV1, EMV2, MSR ISO Track1/2/3
Wall Mount Fixed Type / Swivel Type (75x75, 100x100mm VESA)
Case Color

White & Black (Bezel type only)

Black

Black & White (Bezelless type only)
